Custom Beveled Side Walls Display Box Dieline Generator
Instant quote
Full screen
Design online
Sample services
Mockup
Create Artwork
Instant Quote
You will get:
- HD deline in DXF format, which can be printed freely and further edited with Adobe Illustrator or CAD.
Why cefBox?
- Make your professional dielines in seconds.
- All dielines are customizable online.
- All templates are designed and re-examined by experts and are print ready.
- Unlimited amounts of dieline customization and downloads.
- Friendly Customer Service Support.
Description:
- Parametric Dimension Inputs: Enter custom length, width, depth, and sloped side bevel angles to instantly modify the flat blueprint geometry.
- Instant 3D Fold Simulation: Visualize flat layouts as a fully assembled, interactive 3D digital mockup directly in the browser before exporting.
- Production-Ready Vector Formats: Download clean DXF, PDF, or EPS vector files built with dedicated stroke colors for cut lines and crease scores.
- Metric & Imperial Toggles: Switch seamlessly between millimeters and standard fractional inches for precise physical manufacturing tolerances.
- Auto-Calibrated Tuck Flaps: Adjusts side tuck tolerances automatically based on input material thickness to prevent buckling or loose friction fits.
- Optimized Sheet Layouts: Computes flat nested bounds dynamically to minimize board waste and maximize production yields during bulk die-cutting.
- Saved Layout History: Retains recent template dimension configurations locally so you can tweak structural design variables without starting over.
